What is the formula for consolidation settlement?
Consolidation settlement (S) = C c / (1 + e 0) · H · log10 · (p ' 0 + δ p) / p ' 0. Here, Cc, compression index; e0, initial void ratio of the clay layer; H, thickness of the clay layer; p0 ′, initial effective stress at midpoint of the clay layer; δp increase of effective stress due to pile load. Design example.
What is the U in consolidation settlement?
Obtaining a reliable stress profile from the applied load. ΔH = total settlement, ΔHc = consolidation settlement, ΔH = secondary compression, U = average degree of consolidation. Generally, the final settlement of a foundation is of interest and U is considered equal to 1 (i.e. 100% consolidation) 1. Immediate Settlement
What is the settlement due to total primary consolidation in clay?
The settlement due to total primary consolidation in normally consolidated clay is given by the following equation. Please note that normally consolidated clays have never been subjected to a higher stress than what it is being subjected to now. ΔH = H Cc (1 + e0) log (p0' + Δp) p0'
What is the difference between immediate settlement and consolidation settlement?
Immediate settlement analysis are used for all fine-grained soils including silts and clays with a degree of saturation < 90% and for all coarse grained soils with large co-efficient of permeability (say above 10.2 m/s) 2. Consolidation Settlement (ΔHc) Consolidation settlements are time dependent and take months to years to develop.

How is consolidation settlement calculated?
Degree of Consolidation = Amount of consolidation at a given time with a soil mass / Total amount of Consolidation obtainable under the given stress condition. This also can be written as follows for a clay layer.
What is ultimate consolidation settlement of soil?
Consolidation settlement is time dependent natural process of fully saturated soil due to expulsion of water from the voids and compaction is instantaneous artificial process of partially saturated soil due to expulsion of air from voids.
How are settlements calculated?
13:2451:58Mod-01 Lec-11 Shallow Foundation - Settlement Calculation - I - YouTubeYouTubeStart of suggested clipEnd of suggested clipSoil layer NCC is equal to compression. Index. So either we can use this expression to calculate theMoreSoil layer NCC is equal to compression. Index. So either we can use this expression to calculate the consolidation settlement.
What does ultimate settlement mean?
Ultimate settlement means the total amount of settlement which is predicted, on the basis of a thorough soils investigation performed by an appropriately licensed professional, over the useful life of a structure.
What is total consolidation settlement?
Abstract. Consolidation is the process of dissipation of excess pore pressure. Due to the dissipation of excess pore pressure, the foundations tend to settle. This settlement is known as consolidation settlement.
How is clay settlement calculated?
6:149:18Consolidation Settlement Equations - YouTubeYouTubeStart of suggested clipEnd of suggested clipGet in font in order to find the settlement I'll just multiply the strain by the thickness of theMoreGet in font in order to find the settlement I'll just multiply the strain by the thickness of the clay layer I don't show that equation here but that's all we have to do is take the strain multiplied.
How are final settlements calculated?
Calculation of per day basic: (number of days of non-availed leaves * basic salary) / 26 days ( Avg paid days in a month). As per Section 7 (3) of the Payment of Gratuity Act 1972, Gratuity should be offered within 30 days of the resignation. If you fail to do so you need to pay with interest.
What is the total settlement?
Total settlement refers to the overall change in vertical distance. Differential settlement involves an expected amount that the total settlement will vary between points over a horizontal distance, which can be caused by variations in the foundation soil profile and wall height over a certain distance.
How is early settlement figure calculated?
To calculate your settlement figure, the lender will add up your remaining monthly instalments between now and the end of your agreement and take away any future interest that you won't need to pay. Finally, any arrears will be added. You'll receive your settlement figure in writing to confirm.
What is the difference between consolidation and settlement?
Debt consolidation and debt settlement are strategies for making debt manageable, but they are different methods and bring different results. Debt consolidation reduces the number of creditors you'll owe. Debt settlement tries to reduce the amount of debt you owe.
How can I reduce my consolidation settlement?
Note: the consolidation settlement can be reduced by conducting any of the following: 1. Increase the length of piles (when the length of piles are increased, “H” value in the preceding equation would reduce. “H” is the thickness of the compressible portion of the clay layer).
What is a settlement with examples?
The definition of a settlement is an agreement that resolves a dispute, an agreement officially transferring real estate to a new party, or people making a home in a new place where no one has lived before. An example of a settlement is when divorcing parties agree on how to split up their assets.
What are the three different types of settlement of soil?
There are three main types of soil settlement in geotechnical engineering: Uniform settlement. Differential settlement. Curvature settlement.
What is the difference between consolidation and settlement?
Debt consolidation and debt settlement are strategies for making debt manageable, but they are different methods and bring different results. Debt consolidation reduces the number of creditors you'll owe. Debt settlement tries to reduce the amount of debt you owe.
What is primary consolidation settlement?
Primary consolidation: Soil settlement during which the excess pore water pressure is transferred to the soil's skeleton.
What is primary and secondary consolidation settlement?
When the rate of densification is controlled by the time required for expulsion of fluids, this volume change is called primary consolidation. Secondary consolidation is the volume change controlled by anything else, such as the sliding of particles over each other or compression of particles.
What is the consolidation settlement?
For fine-grained soils, the consolidation settlement often is the major component of the total settlement. As noted previously, consolidation settlement is the time-dependent volume change that occurs as the excess pore water pressure, developed during load application, gradually dissipates and is transferred to the soil skeleton. The consolidation settlement is given by
How to determine the settlement of a foundation?
The elastic settlement of a foundation is determined by assuming that the soil behaves as an elastic material. The basic approach employed is to use the traditional Boussinesq solution for stress changes in an isotropic, elastic medium subjected to a point load applied normal to the surface of a half-space (the ground is a half-space because it does not exist above the ground surface). The elastic settlement of the foundation is given by
What was the pressure of the airtight sheet during the consolidation settlement?
Vacuum pressure measured under the airtight sheet was maintained constantly at about 80 kPa along to the consolidation settlement between October 2008 and December 2009. The water discharge at the beginning of vacuum pumping was about 400 m 3 /day and gradually decreased during consolidation settlement to about 200 m 3 /day.
What is secondary settlement?
Secondary settlement continues after consolidation settlement is complete, as the soil structure gradually readjusts to the new level of effective stress. This process continues indefinitely. The prediction of secondary settlement is of considerable importance with clays of high plasticity and with micaceous and organic soils, but it typically is of minor concern with coarse-grained soils and overconsolidated, low plasticity, inorganic clays. Secondary settlement often is computed from the relation
What are the phases of settlement?
As stated above, when a load is applied to the foundation, three distinct phases of settlement occur: immediate or elastic (ρ e ), consolidation (ρ c ), and secondary settlement (ρ s ):
What is the estimated average degree of consolidation in 2024?
The estimated average degree of consolidation in 2024, according to non-Darcian flow, becomes 84%, corresponding to a settlement of 2.1 m.
Is the embankment more stable than the uncorrected case?
Therefore, the stability of the embankment was evaluated to be more stable than the uncorrected case. Moreover, the pore water pressure induced by embankment load was more clearly identified. The maximum excess pore water pressure of GL − 7 m at the finished level of embankment was about 20 kPa and then decreased to − 54 kPa at the termination of the vacuum operation.
What is the difference between total settlement and differential settlement?
Total settlement is the magnitude of downward movement. Differential settlement is non-uniform settlement. It is "the difference of settlement between various locations of the structure. Angular distortion between two points under a structure is equal, to the differential settlement between the points divided by the distance between them.
What is the final settlement of a foundation?
Generally, the final settlement of a foundation is of interest and U is considered equal to 1 (i.e. 100% consolidation) 1. Immediate Settlement. Immediate settlement takes place as the load is applied or within a time period of about 7 days. Predominates in cohesion less soils and unsaturated clay.
Why is the leaning tower of Pisa undergoing consolidation settlement?
The lean is caused by consolidation settlement being greater on one side. This, however, is an extreme case. The principal settlements for most projects occur in 3 to 10 years.
How much settlement is acceptable for a road embankment?
A fixed-end arch would suffer greatly if the abutments settle or rotate. For road embankments, storage silos and tanks a settlement of 300mm - 600mm may be acceptable, but for machine foundations the settlement may be limited to 5mm 30mm. Different types of construction materials can withstand different degrees of distortion. For example, sheet metal wall panels do not show distress as readily as brick masonry.
What is secondary consolidation?
Secondary consolidation may be the larger component if settlement in some soils, particularly in soils with a large organic component. Secondary consolidation is associated with both immediate & consolidation type settlements, although it is usually not of much significance with immediate settlements.
What happens after primary consolidation?
After primary consolidation the soil structure continues to adjust to the load for some additional time. This settlement is termed secondary consolidation/secondary compression. At the end of secondary consolidation the soil has reached a new K o -state (at-rest state).
What is the value of m in a settlement?
m = number of corners contributing to settlement ΔHi. At the footing center m= 4; and at a corner m = 1, at a side m = 2.
Fig. 9.7 Void ratio to effective pressure curves
curve, primary compression being made up of (i) a reversible part and (ii) an irreversible part. Once the consolidation pressure is extended beyond the original consolidation pressure value (the preconsolidation pressure ), the e p curve follows the trend of the original compression curve.
Typical values of mv are given in Table 9.3
In the laboratory consolidation test the compression of the sample is one-dimensional as there is lateral confinement, the initial excess pore water pressure induced in a saturated clay on loading being equal to the magnitude

Consolidation
- When the construction of the foundation is done(application of additional load), pore water pressure in the saturated clay increases as the hydraulic conductivity of the clay is very small. Some time is required for excess pore water pressed to dissipate and increase the stress to be t…
Primary Consolidation
- The definition of primary consolidation is discussed above under the terminology. Let’s the method of primary Consolidation settlement calculation There are two different stages of soil. 1. Normally Consolidated Soil 2. Over Consolidated Soil It is required to assess the consolidation of soil is done based on the above states. In simple terms, the normally consolidated soil is experie…
Secondary Consolidation
- Secondary consolidation settlement occurs after the completion of dissipation of the excess pore water pressure developed immediately after the application of load. The settlement caused due to the plastic adjustment of the soil fabrics at the end of the primary consolidation is called secondary consolidation. Secondary Consolidation also can be explained as slippage and reorie…
Types of Tests to Find Consolidation Settlement
- One dimensional consolidation test
- Oedometer Test
- Incremental Loading Oedometer
