Settlement FAQs

what is ground settlement meaning

by Arne Schulist Published 2 years ago Updated 2 years ago

Settlement is the downward movement of the ground (soil) when a load is applied to it. The load increases the vertical effective stress exerted onto the soil. This stress, in turn, increases the vertical strain in the soil. This increase in vertical strain causes the ground to move downward.Jun 6, 2018

Full Answer

What is the settlement of the ground?

Settlement: When a load is applied on the ground, it increases the vertical effective stress. This stress increases the vertical strain in the soil. This increase in vertical strain causes the ground to move downward. This downward movement of the ground is called settlement.

What is settlement in geotechnical engineering?

In geotechnical engineering, settlement is defined as the downward vertical movement of the ground due to changes in stresses within it. Excessive ground movements can cause damage in buildings, structures and transport infrastructure, from bridges and tunnels to road pavements and railways.

What are the causes of settlement?

Settlement is most likely to occur when increased vertical stresses are applied to the ground on or above soft or loose soil strata. It is also possible that lowering the ground water, migration of soil fines, deep voids, underground excavation for tunnels, induced ground vibrations and seismic events will cause significant settlement.

What is the difference between settlement and subsidence?

In geotechnical engineering , settlement is defined as the vertical movement of the ground, generally caused be changes in stresses within the earth. Subsidence is a term often used to described ‘caving in’ or sinking of the ground, that may not be associated within changes in soil stresses.


What happens when the ground settles?

As the air and water leave the soil, the solid particles are rearranged and 'settle' into a new compact position. Air is released first, and then water flows out at a rate that depends on the materials in the mix. For example, water disperses faster in fine particles like sand, but slower in dense particles like clay.

What are the three types of soil settlement?

There are three main types of soil settlement in geotechnical engineering: Uniform settlement. Differential settlement. Curvature settlement.

What is differential ground settlement?

Differential settlement is the uneven or unequal settling of a building's foundation. This occurs when the soil under your foundation contracts, expands, or shifts irregularly. Differential settlement causes the structure to settle at a variable rate.

What is settling of soil?

settling, in soil mechanics, refers to sedimentation; i.e., the settling out of solid particles from suspension in water. The velocity of settling depends on the size, shape, and density of the particles, and on the viscosity of the water. Particles may be classified in size by relative settling rates.

What causes ground settlement?

What Causes Settlement of Soils? Settlement occurs from soil consolidation due to a reduction in voids or spaces between soil particles due to applied loads or changes in moisture content. The loss of moisture in soils causes consolidation.

Why settlement of soil is important?

Settlement is an important criterion in the design of the foundations. Foundation settlement must be estimated carefully to ensure stability of buildings, towers, bridges, and any high cost structures. The main reason for the settlement occurrence is the compressive deformation of the soil.

How do you prevent ground settlement?

Install drainage ditches or drain pipes to prevent soil settlement in areas. If water has a path to follow, it is less likely to erode land areas. Create small mounds of soil in between plant rows to keep soil from shifting or settling due to a slope in the field.

How much foundation settlement is too much?

How much foundation settlement is too much? The industry standard is 1 inch of differential settlement in 20 feet. Anything greater than this can be considered too much.

How can I avoid foundation settlement?

2:213:46Differential Settlement. - Its Causes and How to Prevent it - YouTubeYouTubeStart of suggested clipEnd of suggested clip1 do proper geotechnical investigation of the soil. To study the surrounding environment 3 the soilMore1 do proper geotechnical investigation of the soil. To study the surrounding environment 3 the soil over which the building is constructed must not be expansive in nature.

What are the types of soil settlement?

The total settlement of the ground consists of 3 components: immediate settlement (commonly referred to as elastic settlement, although this is a misnomer), consolidation settlement (or primary settlement) and creep settlement (or secondary settlement).

What is ground settlement in construction?

Introduction. Settlement is the downward movement of the ground caused by a load consolidating the soil below it or causing displacement of the soil. Settlement often refers to the downward movement of the ground around an excavated space, such as that for tunnels, shafts, or basements.

Which soil has more settlement?

Immediate settlement take place mostly in coarse grained soils of high permeability and in unsaturated fine-grained soils of low permeability.

What are the types of soil settlement?

The total settlement of the ground consists of 3 components: immediate settlement (commonly referred to as elastic settlement, although this is a misnomer), consolidation settlement (or primary settlement) and creep settlement (or secondary settlement).

What are the types of settlement?

The four main types of settlements are urban, rural, compact, and dispersed. Urban settlements are densely populated and are mostly non-agricultural. They are known as cities or metropolises and are the most populated type of settlement. These settlements take up the most land, resources, and services.

What is secondary settlement of soil?

This process of creep is sometimes known as "secondary consolidation" or "secondary compression" because it also involves gradual change of soil volume in response to an application of load; the designation "secondary" distinguishes it from "primary consolidation", which refers to volume change due to dissipation of ...

Which soil has more settlement?

Immediate settlement take place mostly in coarse grained soils of high permeability and in unsaturated fine-grained soils of low permeability.

What is the difference between creep and immediate settlement?

Since soil particles are practically incompressible, consolidation settlements is caused by a reduction in voids due to gradual squeezing out of water. Finally, creep settlement occurs under a constant load and is depended on the stress history, the type of soil and the anisotropy of the soil.

How long does creep settlement last?

The settlement process may be completed almost immediately or may last for a significant amount of time (even decades) depending on the soil’s permeability and water drainage paths.

What is the term for the movement of soil in the vertical direction?

Settlements refer to the soil’s movement in the vertical direction typically induced by stress changes. The total settlement of the ground consists of 3 components: immediate settlement (commonly referred to as elastic settlement, although this is a misnomer), consolidation settlement (or primary settlement) and creep settlement (or secondary settlement).

What is the term for the movement of the ground downward?

This increase in vertical strain causes the ground to move downward. This downward movement of the ground is called settlement .

What is downward movement of the ground called?

When downward movement of the ground occurs over a large area due to increase in vertical strain in the soil. Then this movement is sometimes called Subsidence.

Examples of settlement in a Sentence

I got the house in the divorce settlement. The parties have not been able to reach a settlement in the case.

Legal Definition of settlement

Subscribe to America's largest dictionary and get thousands more definitions and advanced search—ad free!

What Does Settlement Mean?

Settlement is defined as the vertical movement of soil in the downward direction especially in soft or loose soil strata. Trenchless technology involves the installation of pipes below the ground surface without digging a trench. Different methods such as horizontal directional drilling (HDD), pipe ramming and microtunneling are used depending on soil characteristics and purpose of installation.

What is the difference between a large settlement and a systematic settlement?

Settlement can be of two types namely, systematic and large. Systematic settlement occurs as a result of voids in the annular space between the pipe and the soil due to collapse or elastic deformation. Large settlement occurs as a result of ground loss due to over-excavation creating voids and sinkholes above the borehole.

Can soil settlement be caused by geotechnical investigation?

Soil settlement can be caused in any of these methods if proper geotechnical investigation to determine the correct method suitable for soil type is not carried out.

What is a settlement?

A settlement is a place where people live. It can range in size from an isolated dwelling to a million city. The site of a settlement is the location where it is built. It describes the physical nature of where a settlement is located. Factors such as water supply, defence, quality of soil, building materials, climate, ...

What factors were taken into account when establishing settlements in the past?

Factors such as water supply, defence, quality of soil, building materials, climate, shelter and defence were all taken into consideration when establishing settlements in the past. The situation of a settlement is the description of the settlement in relation to physical features around it and other settlements.

What is settlement in a structure?

Settlement in a structure refers to the distortion or disruption of parts of a building due to. unequal compression of its foundations; shrinkage, such as that which occurs in timber-framed buildings as the frame adjusts its moisture content; or.

Is it normal for buildings to settle?

Some settlement is quite normal after construction has been completed, but unequal or differential settlement may cause significant problems for buildings. Traditional green oak-framed buildings are designed to settle with time as the oak seasons and warps, lime mortar rather than Portland cement is used for its elastic properties and glazing will often employ small leaded lights which can accept movement more readily than larger panes.
